Mobile Stone Crusher

Handling hard rocks and raw stones on construction or mining sites can be challenging. A mobile stone crusher solves this problem efficiently. It allows contractors to crush hard materials like basalt, iron ore, cobblestones, and quartz directly on site. By reducing transport and labor costs, a mobile crusher improves productivity and project flexibility. Whether you need a portable crusher for a small project or a larger portable stone crusher for heavy-duty operations, this equipment is designed for efficiency and reliability.

What Is a Mobile Stone Crusher

A mobile stone crusher is an all‑in‑one wheeled or tracked crushing unit. It integrates feeding, jaw crushing, conveying, and control in one compact system. Unlike fixed plants, it can move freely on roads and job sites without complex foundation work. It works as a mobile crusher for primary crushing, especially for hard and abrasive materials. It also serves as a portable crusher for short‑term projects, demolition sites, and scattered quarry points. As a portable stone crusher, it brings high flexibility to any operation that needs fast relocation and stable output.

REQUEST A FREE QUOTE

Parameters of YG Mobile Stone Crusher

Model		C6X110	C6X125	C6X145	C6X160	C6X200
Size of Feed Opening(mm)		1100	1250	1450	1600	2000
Size of feed openning width(mm)		850	950	1100	1200	1500
Power(kw)		160	160	200	250	400
Rotate speed(rpm)		230	220	220	220	200
Product size(mm)	Tight side discharge	T/H	T/H	T/H	T/H	T/H
	opening(mm)
0- 105	70
0- 120	80	160- 240
0- 135	90	180- 260
0- 150	100	200- 280	240- 340
0- 185	125	250- 360	280- 410	320- 470
0- 225	150	300- 430	340- 480	370- 550	420- 610
0- 260	175	340- 490	370- 550	430- 630	470- 700	620- 890
0- 300	200	380- 550	420- 620	480- 710	530- 790	690- 1000
0- 340	225		470- 690	540- 790	590- 880	770- 1100
0- 375	250		520- 760	600- 870	650- 970	850- 1200
0- 410	275			660- 950	700- 1060	930- 1300
0- 450	300				750- 1100	1000- 1500

REQUEST A FREE QUOTE

Strong Points of YG Mobile Stone Crusher

• Excellent for Hard Rock

The jaw structure delivers a strong squeezing force. It easily crushes basalt, river stone, quartz, iron ore, and other hard materials. It works stably as a primary crusher without frequent jamming.

• Dual Power Choice

Users can choose a diesel drive for areas without a power supply. Electric drive saves cost and reduces noise for long‑term fixed use. This dual design improves the usability of the mobile crusher.

• High Mobility & Fast Setup

The compact chassis moves easily on roads and rough terrain. It arrives at the site and starts working in a short time. No long installation or complicated foundation is needed. This is a key advantage of the portable crusher.

• Stable & Reliable Performance

The whole frame uses heavy‑duty steel. The structure is strong enough for long hours of vibration and load. It runs smoothly even under continuous hard rock feeding.

• Easy Adjustment & Simple Operation

Users can adjust discharge size quickly through a hydraulic system. The control panel is clear and easy to learn. Workers can operate the portable stone crusher with basic training.

• Low Maintenance & Long Service Life

Wearing parts use high‑strength materials. They last longer under abrasion. Daily maintenance is simple, which reduces downtime and operating costs.

REQUEST A FREE QUOTE

Applications of Mobile Stone Crusher

Quarry primary crushing – breaks raw hard stone into medium-sized aggregates

Mining projects – crushes iron ore, quartz, and other minerals on site

Construction job sites – process rock and concrete for road base

Demolition recycling – crushes waste concrete into reusable materials

Short‑term infrastructure projects – provide fast and flexible crushing support

How Mobile Stone Crusher Improves Efficiency & Output

• It eliminates long‑distance material transport and reduces fuel costs
• Stable hard rock crushing reduces downtime and raises hourly output
• Fast setup means more working time per project
• Simple operation lowers labor demand and training cost
• The dual power system keeps production running in any condition

REQUEST A FREE QUOTE

Real Customer Case from Nigeria

Our customer Chukwudi Okonkwo is from Nigeria. He runs a quarry business and needs a reliable solution for hard basalt.He found YG through a product search and left an inquiry. Our sales team discussed the material type, capacity needed, and site condition. We recommended a suitable mobile stone crusher for primary hard rock crushing. After confirming the configuration, he placed the order. We finished production and quality testing on time. We sent detailed test videos and photos for confirmation. The machine was shipped by sea to Nigeria.

After arrival, Chukwudi’s team installed and started the machine quickly with our remote guidance.

His feedback includes clear data:

• The machine handles basalt smoothly with no blockage
• Capacity reaches around 130–150 t/h, higher than expected
• Daily output increased by about 45% compared to the old equipment
• Fuel and transport costs decreased by about 30%
• Operation is easy, and maintenance is simple

About YG Company

YG is a professional manufacturer with over 20 years of experience in construction and mining machinery. We focus on stable design, reliable quality, and real customer needs. Our mobile stone crusher and related equipment have CE and ISO certifications. We provide full pre‑sales consultation, customized solutions, and timely after‑sales support. Besides mobile crusher series, we also produce stone splitters, excavators, and other heavy equipment. We aim to help customers improve efficiency, reduce costs, and achieve stable business growth.

If you need a reliable mobile stone crusher for hard rock primary crushing, contact YG for details and support.
