A Concrete Cement Floor Shot Blaster is used to prepare concrete and other hard surfaces before repair, coating, painting, or resurfacing. It uses small steel shots to clean the surface and remove weak layers, old coatings, dirt, and other unwanted material. The process also creates a more suitable surface for the next construction step. Compared with manual grinding, shot blasting covers a larger working area and gives a more even result. The equipment can be used on floors, bridges, parking areas, workshops, warehouses, and some road surfaces. For contractors and equipment distributors, the right machine can also reduce preparation time and make daily surface work easier to manage.
Concrete Shot Blasting Machine Product Parameters
YG Machinery offers several models for different working widths and surface cleaning needs.
| Model | YG-270(Single) | YG550/600(Double) | YG-850(Double) | |
| Shot Blasting Wheel Diameter | 200mm | |||
| Working width | 270 mm | 550/600 mm | 800 mm | |
| Walking speed | 0.5~20 m/min | 0.5~33 m/min | ||
| Concrete surface cleaning efficiency | ≥180 m2/h | ≥400 m2/h | ≥600 m2/h | |
| Steel plate surface cleaning efficiency | 15-25 m2/h | 75-100 m2/h | 100-160 m2/h | |
| Dust connection pipe diameter | 120 mm | 150 mm | ||
| Suggest the diameter of steel balls | 1.2-1.5 mm | 1.5-1.8 mm | ||
| Steel pill consumption | 10 g/m2 | |||
| Supporting dust collector | Seven-core automatic backflush vacuum cleaner | Eight-core automatic backflush vacuum cleaner | ||
| Shot wheel motor | Power consumption | 11 kW | 11*2 kW | 15*2 kW |
| Input Current | ≤ 15 A | ≤ 22*2 A | ≤ 28*2 A | |
| Walking motor | Power consumption | 0.5 kW | 1.5 kW | |
| Input Current | 1 A | 3 A | ||
| Size (mm) | 1000*300*1100 | 1950*720/775*1400 | 1950*1020*1550 | |
| Weight | 150 kg | 570 kg | 700kg | |
| Power connection requirements | Supporting the dust collector | |||
Working Advantages of Concrete Floor Shot Blaster
- Even surface preparation: The machine applies the blasting action across the working path, helping create a more consistent surface.
- Fast removal of unwanted layers: Steel shots can remove weak concrete layers, paint, coating residue, dirt, and other surface material without relying only on hand tools.
- Dust control: The machine works with a supporting dust collection system to collect dust generated during operation. This helps keep the work area cleaner and improves visibility.
- Suitable for follow-up work: After shot blasting concrete, the surface can be prepared for coating, repair materials, waterproofing, or other treatment processes.
- Easy process control: Operators can adjust the working method to match the surface condition and project requirements instead of using one fixed approach for every job.
The result is a practical surface preparation process for projects where clean and properly treated concrete is required before the next stage.
Application Areas of Road Shot Blasting Machine
- Concrete floor preparation: The equipment can be used in workshops, warehouses, factories, parking structures, and commercial buildings. It helps remove surface contamination before coating or repair work.
- Road and bridge maintenance: A Cement Floor Shot Blasting Machine can be used for selected road, bridge, and pavement preparation tasks where surface cleaning or texture treatment is required.
- Coating and paint removal: It can remove existing coatings and prepare the base surface before applying a new layer. This is useful when the old finish is no longer suitable for continued use.
- Industrial floor renovation: Manufacturing sites often need floor maintenance because of traffic, equipment movement, and repeated use. Shot blasting provides a mechanical way to prepare worn surfaces for renovation.
- Bead blasting work: A bead blaster for concrete floors may be used when the project needs controlled surface treatment with blasting media. The actual media selection should match the substrate and required finish.
Concrete Cement Floor Shot Blaster Operation Tips
- Inspect the surface: Remove loose objects, large debris, and obstacles before starting. Cracks or damaged sections should also be checked.
- Choose suitable shot media: The size and type of steel shot affect the treatment result. Use media suitable for the material and the required surface profile.
- Connect dust collection correctly: Make sure the dust collection system is properly connected before operation. This helps control airborne dust during blasting.
- Keep the machine moving steadily: Sudden stops or uneven movement may produce an inconsistent surface. A steady operating speed usually gives better control.
- Check the finished surface: After each working area is completed, inspect the result before continuing to the next section. This can help avoid unnecessary repeat work.
Concrete Floor Shot Blaster Buying Questions
What can a Concrete Cement Floor Shot Blaster remove?
It can remove many types of unwanted surface material, including loose concrete layers, old coatings, paint residue, dirt, and similar contaminants. The final effect depends on the surface condition and selected blasting media.
Can this machine be used before epoxy coating?
Yes. Shot blasting is commonly used as part of concrete surface preparation before coating systems such as epoxy. The surface should be checked after blasting to confirm that it is suitable for the planned coating.
What is the difference between shot blasting and grinding?
Shot blasting uses steel shots thrown against the surface, while grinding uses an abrasive tool that works directly against the surface. The better method depends on the material, existing coating, required finish, and project size.
How should I choose a model?
Consider the working area, required cleaning level, floor condition, available dust collection system, and expected daily workload. A narrower machine may suit smaller or restricted areas, while a wider model can cover more surface in larger projects.
Can I get a price and quotation before ordering?
Yes. You can contact YG Machinery for the current Concrete Cement Floor Shot Blaster price, model selection, configuration details, and a formal quote based on your project needs.
Concrete Shot Blasting Machine From YG Machinery
YG Machinery has more than 20 years of machinery manufacturing experience and provides CE-certified equipment for overseas markets. Its product range also includes a Road Shot Blasting Machine, Road Line Marking Machine，Mobile Fog Cannon, Polyurethane Spray Machine, and other construction equipment. Contact YG Machinery for machine selection, configuration support, and a direct quote for your project.【WhatsApp/WeChat/Phone/Skype】+86 13937183602
