Dust is a serious problem on construction sites, quarries, and demolition projects. It harms worker health, bothers nearby communities, and can lead to environmental fines. Fixed spray systems are hard to move and waste water. A Trailer Fog Cannon moves with your work, delivers a fine mist, and captures dust efficiently. It keeps the air clean and helps you meet regulations without extra hassle.
Specifications of Trailer Fog Cannon
| Parameter | YG-50 | YG-60 | YG-80 | YG-100 | YG-120 |
| Model | YG-50 | YG-60 | YG-80 | YG-100 | YG-120 |
| Spray Range | 50 meters | 60 meters | 80 meters | 100 meters | 120 meters |
| Spray Flow | 8 m³/h | 8 m³/h | 12 m³/h | 12 m³/h | 15 m³/h |
| Water Pump Stroke | 140 meters | 140 meters | 160 meters | 180 meters | 185 meters |
| Atomized Particles | 30-150 μm | 30-150 μm | 30-150 μm | 30-150 μm | 30-150 μm |
| Horizontal Rotation Angle | ±160° adjustable | ±320° adjustable | ±320° adjustable | 160° adjustable | 0-320° adjustable |
| Up and Down Pitch Angle | -5° to 35° | -5° to 35° | -5° to 35° | -10° to 45° | 0° to 60° |
| Total Power | 14.5 kW | 24.75 kW | 45.25 kW | 75 kW | 91 kW |
| Power Supply | 380V 50Hz three phase | 380V 50Hz three phase | 380V 50Hz three phase | 380V 50Hz three phase | 380V 50Hz three phase |
| Blower Motor Power | 11 kW | 18.5 kW | 37 kW | 55 kW | 75 kW |
| Water Pump Motor Power | 3 kW (Multistage centrifugal pump) | 5.5 kW (Multistage centrifugal pump) | 7.5 kW (Multistage centrifugal pump) | 11 kW (Multistage centrifugal pump) | 15 kW (Multistage centrifugal pump) |
| Noise Reduction Technology | Sinusoidal noise reduction | Sinusoidal noise reduction | Sinusoidal noise reduction | Sinusoidal noise reduction | Sinusoidal noise reduction |
| Lifting Mechanism | Hydraulic lifting | Hydraulic lifting | Hydraulic lifting | Hydraulic lifting | Hydraulic lifting |
| Left and Right Rotation Structure | High quality reduction motor | Hydraulic rotation | Hydraulic rotation | Hydraulic rotation | Hydraulic rotation |
| Number of Nozzles | 40 | 58 | 80 | 120 | 120 |
| Dimensions | 2000*1500*1500 mm | 1050*1600*2400 mm | 1400*1600*2500 mm | 2700*2000*2300 mm | |
| Weight | 400 kg |
All models include sinusoidal noise reduction, hydraulic lifting, and a durable trailer chassis. The atomized particle size (30‑150 microns) ensures effective dust capture with minimal water usage. This Trailer Dust Suppression Cannon saves up to 80% more water than traditional sprays.
How Does a Trailer Fog Cannon Work?
The Fog Cannon Sprayer uses a high‑pressure pump to push water through special nozzles. The nozzles break water into tiny droplets – this is atomization. A powerful fan blows these droplets out of the cannon barrel over a long distance. When the mist meets airborne dust, the droplets attach to the dust particles. The heavier particles then fall to the ground. This process is fast and covers large areas. A sprayer fog cannon can reduce dust by 60‑80% on site. It works well even in windy conditions. The trailer mounted fog cannon is easy to position because you can rotate it horizontally and adjust the pitch angle. You can aim the mist exactly where dust is generated.
User Case in Oman
An Omani construction contractor worked on a major infrastructure project near Muscat. Dust from earthmoving and crushing operations caused frequent complaints from local residents. The contractor needed a mobile dust control solution. He chose a YG Trailer Fog Cannon after comparing several options. The machine was towed to the site and set up in minutes. It covered the entire working area with fine mist. Within two weeks, air quality improved noticeably. Complaints stopped. The site manager commented, “This cannon is a real game‑changer. It cut our dust levels fast and uses much less water than our old system.” He also noted that the unit’s mobility made it perfect for their changing work zones. The contractor was so satisfied that he bought a second trailer mounted fog cannon for another project.
FAQ
Q: What spray range do I need for my site?
YG offers ranges from 50 to 120 meters. Choose a model based on your site width and dust source distance. Contact us for a recommendation.
Q: Can this machine run on a standard power supply?
All models use 380V 50Hz three‑phase power. Make sure your site has that available. We can also discuss other options.
Q: How much water does it consume?
It uses 8 to 15 m³ per hour depending on the model. But because the mist is fine, it covers more area with less water. You save money on water bills.
Q: How do I get a price for a specific model?
Request a quote from YG Machinery. We will give you a competitive price based on your model choice and quantity.
YG Machinery Trailer Dust Suppression Cannon for Sale
YG Machinery is a reliable manufacturer of industrial equipment. Our mist cannon is built for tough jobs. It is mobile, powerful, and simple to operate. Besides dust control, we also offer other useful machines like the Concrete Delivery Pump, Mobile Fog Cannon, and Electric Sweeper,etc.All our products are tested for durability and performance. When you buy from YG, you get solid support and competitive pricing. We are ready to help you select the right Trailer Fog Cannon for sale. Contact us today for a quote. Ask about our current prices and delivery times.【WhatsApp/WeChat/Phone/Skype】+86 13937183602
