An Expandable Modular House is designed for projects that need usable indoor space while keeping transport dimensions under control. The structure changes from a folded transport unit into a larger enclosed space at the destination. This makes the product suitable for temporary housing, site facilities, offices, and other modular building projects. Buyers can select a model based on required floor space, transport conditions, and installation location.
Specifications of Expandable Modular House
The available models differ mainly in length, internal space, folded width, and total mass. These differences directly affect transportation and site planning.
| 20FT Basic Characteristics | External dimension (mm) | W6320*L5900*H2480(Side 2270) |
| Internal dimension (mm) | W6160*L5560*H2240(Side 2150) | |
| Folded state (mm) | W2200*L5900*H2480 | |
| Total mass (kg) | 2500 | |
| 30FT Basic Characteristics | External dimension (mm) | W6360*L9000*H2480(Side 2180) |
| Internal dimension (mm) | W6200*L8660*H2240(Side 2060) | |
| Folded state (mm) | W2200*L9000*H2480 | |
| Total mass (kg) | 3750 | |
| 40FT Basic Characteristics | External dimension (mm) | W6240*L11800*H2480(Side2180) |
| Internal dimension (mm) | W6080*L11540*H2200(Side2060) | |
| Folded state (mm) | W2200*L11800*H2480 | |
| Total mass (kg) | 4400 | |
| Smaller Fold Size | External dimension (mm) | W4820*L5900*H2480(Side2270) |
| Internal dimension (mm) | W4660*L5560*H2240(Side2150) | |
| Folded state (mm) | W700*L5900*H2480 | |
| Total mass (kg) | 1850 |
Selection of Expandable Modular House
- Select by Required Indoor Space:Start with the usable space needed after expansion. The 20FT model suits projects with moderate space needs, while the 30FT and 40FT models provide longer internal areas for larger layouts.
- Check the Folded Dimensions:Compare the folded size with the planned transport route, loading area, and storage space. The standard models have a folded width of 2200 mm, while the Smaller Fold Size model has a width of only 700 mm.
- Consider Total Mass:The model weight affects transportation and handling arrangements. The listed total mass ranges from 1850 kg for the Smaller Fold Size model to 4400 kg for the 40FT model.
- Match the Model to the Project:Choose the model according to its final expanded dimensions and intended use. A 20FT unit can work for smaller facilities, while a 40FT unit provides the longest internal space.
- Plan for Future Relocation:If the unit may be moved to another site, consider both its expanded size and folded dimensions. A portable expandable home should fit not only the current site but also possible future transport requirements.
- Compare the Total Purchase Cost:Before you buy, compare the model, quantity, shipping requirements, and any requested configuration. These details provide a more useful basis for checking the final price and requesting a quote.
Advantages of Expandable Modular House
- Flexible space after transport.The structure uses a folding concept to reduce its width during transportation. Once positioned at the project site, it expands to provide a much larger usable area.
- Several size options.The 20FT, 30FT, 40FT, and Smaller Fold Size models cover different project requirements. Buyers can compare internal dimensions instead of selecting a unit based only on its external name.
- Reduced folded width.The standard models have a folded width of 2200 mm. The Smaller Fold Size model reduces this measurement to 700 mm. This difference can influence loading, storage, and delivery planning.
- Clear weight information.The listed mass ranges from 1850 kg to 4400 kg. Knowing the exact model weight allows buyers to prepare suitable transport and handling arrangements before shipment.
- Suitable for different layouts.The larger internal dimensions allow the units to be planned for living, working, or service space. A folding container house can therefore serve different project functions without changing the basic transport concept.
- Different purchasing options.Customers can choose a model according to project size instead of buying one fixed configuration. This approach is useful for single-unit projects as well as multiple-unit orders.
FAQ about Expandable Modular Home
What sizes can I buy?
The available options include 20FT, 30FT, 40FT, and a Smaller Fold Size model.
Which model has the largest internal length?
The 40FT model has an internal length of 11540 mm and an external expanded length of 11800 mm.
Which model has the smallest folded width?
The Smaller Fold Size model has a folded width of 700 mm. The other three models have a folded width of 2200 mm.
How much does the product cost?
The final price depends on the selected model, order quantity, configuration, and shipping requirements. Buyers can request a quote based on their project details.
Can I order a unit for a temporary project?
Yes. A foldable modular home can be considered when the building may need to serve a project for a limited period and may later be relocated.
Are expandable prefab homes suitable for different projects?
Yes. The available sizes allow buyers to select different space capacities for accommodation, offices, site facilities, and other modular building needs.
YG Machinery Expandable Modular House Supply
YG Machinery supplies modular building products for international buyers, including the Foldable Prefab House, 20FT Expandable Container House, and 40FT Expandable Container House. Buyers can contact YG Machinery to confirm model availability, price, shipping requirements, and request a quote based on quantity and destination.【WhatsApp/WeChat/Phone/Skype】+86 13937183602
