A paper making machine transforms pulp into continuous paper sheets for packaging and industrial use. The YG 2400mm model produces high-strength corrugated paper and kraft paper with a daily output of 30 tons. This paper production machine operates at working speeds of 80–100 m/min with a design speed of 150 m/min. It serves paper mills seeking reliable, cost-effective equipment for packaging paper manufacturing.
Specifications of the YG 2400mm Paper Making Machine
| Parameter | Specification |
| Main product | High-strength corrugated paper, Kraft paper |
| Basic weight | 100–220 g/m² |
| Trimmed width | 2400 mm |
| Width on reel | 2450 mm |
| Production capacity | 30 t/d |
| Width of wire | 2950 mm |
| Working speed | 80–100 m/min |
| Design speed | 150 m/min |
| Center distance | 2400 mm |
| Drive type | AC frequency inverter sectional drive |
| Dryness after wire section | 18–19% |
| Dryness after press section | 46–47% |
| Finished product dryness | 92% |
| Customization | Available upon request |
The machine uses a Fourdrinier wire system. Pulp flows from the headbox onto the moving wire mesh. Water drains through the wire, forming a wet paper web. The web then moves to the press section, where heavy rolls squeeze out more water. Finally, the dryer section uses steam-heated cylinders to remove remaining moisture. The result is dry, finished paper ready for winding.
Advantages of the YG Paper Making Machine
- High production capacity – This paper machine produces 30 tons per day. That is enough for medium to large paper mills. You can meet customer orders without delays.
- Energy-efficient drive system – The AC frequency inverter sectional drive controls each section separately. This reduces power waste. It also gives you precise speed control for better paper quality.
- Excellent dryness levels – The wire section reaches 18–19% dryness. The press section reaches 46–47%. The finished product reaches 92% dryness. Higher dryness means less energy needed for drying. That saves you money on fuel or electricity.
- Wide paper weight range – The machine handles 100–220 g/m² basic weight. You can produce lightweight liner paper or heavier kraft paper on the same paper production machine.
- Durable construction – Built with heavy-duty materials. The machine runs continuously with minimal downtime. Maintenance is straightforward.Customizable options – We can adjust specifications based on your needs. Tell us your required output, paper grade, or special features. We will tailor the machine for your mill.
Applications of the Paper Making Machine
- Corrugated board production – Corrugated paper is lightweight but strong. It absorbs shocks during shipping. Over 80% of corrugated paper can be recycled. This makes it popular for shipping boxes and product packaging.
- Kraft paper packaging – Kraft paper has high tear strength. It is used for shopping bags, wrapping paper, and industrial sacks. The YG machine produces kraft paper at 100–220 g/m². That covers most packaging needs.
- Linerboard for boxes – Linerboard is the flat outer layer of corrugated boxes. This making paper machine produces linerboard with consistent thickness and strength.
- Fluting medium – Fluting is the wavy inner layer of corrugated board. The machine produces fluting paper at the required grammage. This gives your boxes crush resistance.
- Recycled paper products – The machine can process recycled pulp. This helps you reduce waste and lower raw material costs. Many buyers prefer eco-friendly packaging today.
FAQ
Q: What is the price of this paper making machine?
A: The price depends on customization options, accessories, and shipping costs. Contact us for a quote. We offer competitive pricing for high-quality equipment.
Q: Can I buy a machine with different specifications?
A: Yes. We customize the machine based on your needs. Tell us your required capacity, paper width, or paper grade. We will adjust the design accordingly.
Q: What raw materials can this making paper machine use?
A: It can use virgin pulp, recycled paper, or waste paper. This flexibility helps you source materials locally and reduce costs.
Q: What is the working speed?
A: The working speed is 80–100 m/min. The design speed is 150 m/min. This gives you room to increase production if needed.
Q: Do you offer warranty and support?
A: Yes. We offer a 1-year warranty and 24/7 technical support. Our team answers your questions anytime.
About YG Machinery
YG Machinery is a professional manufacturer of paper machinery and paper converting equipment. We supply machines to businesses worldwide. Our product range includes tissue paper making machine, toilet paper making machine,plastic bag machine, sanitary napkin manufacturing machine, etc. We focus on quality, reliability, and customer service. Every machine is tested before shipment. We offer free layout advice, installation guidance, and after-sales support. Contact us for a quote or to discuss your project. We are ready to help you find the right equipment for your paper mill.【WhatsApp/WeChat/Phone/Skype】+86 13937183602
