An Electric Concrete Pump runs on an electric motor instead of diesel. This machine delivers smooth, steady power for hours of continuous concrete placement. There is no exhaust fume, no loud engine noise, and no fuel tank to refill. For contractors working in cities, indoors, or near residential areas, this pump provides a cleaner and quieter way to move concrete. Electric models also reduce daily operating costs because electricity costs less than diesel. Many construction teams now choose this equipment to meet environmental rules and improve working conditions on site. Whether you need a commercial concrete pump for a large project or a smaller unit for tight spaces, electric models deliver consistent performance and lower long-term expenses.
Specifications of Electric Concrete Pump
| Model | YG-20 | YG-30 | YG-40 | YG-50 |
| Motor power | 22KW | 37KW | 45KW | 55kw |
| Maximum outlet pressure | 26mpa | 28mpa | 28mpa | |
| Maximum theoretical throughput | 16-18m³/h | 20-22m³/h | 35m³/h | |
| The maximum particle size of aggregate | ≤20mm | ≤30mm | ≤40mm | |
| Vertical conveying distance | 40m | 80m | 120m | 150m |
| Horizontal conveying distance | 80m | 140m | 2600m | 300m |
| Diameter of the conveying pipe | 80mm | φ80 (100) mm | φ100 (80) mm | Φ125/100mm |
| Whole machine weight | 1600kg | 2200kg | 2400kg | 2500kg |
| Dimensions | 3400x1200x1600mm | 3600x1500x1600mm | 4000x1500x1550mm | 4200*1700*1750mm |
Key Advantages of Electric Concrete Pump
- Quiet Operation:The electric motor runs much quieter than a diesel engine. This makes it suitable for night work, indoor projects, and residential areas. Noise complaints from neighbors are less likely. Teams can work longer hours without disturbing the surrounding environment.
- Low Maintenance Cost:There is no fuel engine to service. The electric system has fewer moving parts that wear out. This means fewer repairs and lower maintenance expenses over the life of the machine. Routine checks are simple and quick.
- Steady Pumping Performance:The electric motor provides consistent power output. The pumping pressure remains stable even during long work hours. This reliability is important for projects that require continuous concrete flow.
- Zero Exhaust Emissions:The machine produces no exhaust fumes. Workers are not exposed to diesel smoke or harmful gases. This creates a safer work environment, especially in enclosed spaces like basements or tunnels.
- Long Service Life:Electric systems are known for durability. With proper care, this pump can operate for many years with few breakdowns. The sturdy frame and quality components protect the machine from daily wear.
Applications of Electric Concrete Pump
- Residential Construction:Houses, apartment buildings, and townhouses all need concrete foundations, slabs, and walls. The Concrete Pump moves concrete quickly from the mixer to the formwork. Its quiet operation is a plus in neighborhoods where noise rules are strict. A mini pump or portable concrete pump works well for these smaller residential jobs.
- Commercial Building Projects:Offices, shopping centers, and warehouses require large volumes of concrete. A commercial concrete pump handles these jobs with high output and steady pressure. The machine pours floors, columns, and beams efficiently, reducing labor time.
- Infrastructure and Road Work:Bridges, overpasses, and road repairs demand reliable concrete delivery. The pump can send concrete over long horizontal distances and to elevated areas. This reduces the need for cranes or manual carrying. A stationary concrete pump is well suited for these larger infrastructure tasks.
- Indoor and Confined Spaces:Basements, tunnels, and underground parking structures have limited access. It fits through standard doorways and works in tight areas. There is no exhaust to vent, so the machine can operate safely indoors.
- Rural and Remote Sites:For smaller jobs in rural areas, a concrete portable pump provides the right balance of power and mobility. These compact units are easy to transport and set up. They work well for farm buildings, small bridges, and village road projects.
- Urban Construction Sites:Cities often have noise and emission regulations. The machine meets these rules without sacrificing performance. It runs clean and quiet, making it a preferred choice for urban contractors.
FAQ
How does an Electric Concrete Pump work?
The electric motor powers a hydraulic system. This system pushes concrete through a pipeline to the pouring point. A mixer truck feeds concrete into the hopper. The pump then moves it forward with steady pressure. Operators control the flow rate from a simple panel.
What is the difference between an electric and a diesel concrete pump?
An electric pump runs on grid power. It produces no exhaust and operates quietly. A diesel pump runs on fuel and can work in areas without electricity. Electric pumps have lower operating costs because electricity is cheaper than diesel. They also need less maintenance since there is no engine to service.
Can I use it for high-rise buildings?
Yes. Models like the YG-50 can pump concrete up to 150 meters vertically. The high-pressure system delivers concrete to upper floors without losing flow. This makes it suitable for multi-story residential and commercial buildings.
What size electric concrete pump do I need?
The right size depends on your project volume and pumping distance. Small jobs like house slabs work well with a mini concrete pump or portable concrete pump. Larger commercial projects need a higher output model like the YG-40 or YG-50. Check the throughput and distance specs to match your needs.
Is a concrete pump for sale available with different power options?
Yes. Many models come in both electric and diesel versions. The electric option is best for sites with stable power supply. The diesel option works where electricity is not available. Both types offer reliable performance for different job conditions.
What maintenance does it require?
Routine maintenance includes checking hydraulic fluid levels, inspecting hoses, and cleaning the system after each use. The electric motor needs minimal service compared to a diesel engine. Regular inspections help prevent breakdowns and extend machine life.
Can I get a price quote for it?
Yes. Contact YG Machinery directly for a price quote. The team can provide pricing based on your model choice, project requirements, and shipping destination. Request a quote to get accurate costs for your specific needs.
Why Choose YG Machinery
YG Machinery backs every Concrete Pump with rigorous factory testing and a full performance check before delivery. Global technical support and a ready supply of spare parts help prevent extended downtime. Customization options include voltage adjustments, pipe size changes, and other project-specific modifications. Shipping is flexible, and warranty terms are clear and fair. The product line covers Mini Concrete Pump, Crawler Concrete Pump, and Concrete Delivery Pump for different site conditions. For a price quote and detailed specs that fit your needs, reach out to YG Machinery.【WhatsApp/WeChat/Phone/Skype】+86 13937183602
