A Small Trailer Concrete Pump is built for contractors who need concrete placement in tight spaces. Full-size pumps are too large for many job sites. They cannot fit through narrow gates. They are hard to move between floors. They cost more to transport and operate. This machine solves those problems.The YG series Portable Concrete Pumping Machine is compact and towable. It hooks up to a pickup truck or van. It moves easily from one site to the next. It pumps concrete at rates from 6 m³/h up to 22 m³/h. It reaches vertical heights up to 120 meters and horizontal distances up to 260 meters. This pump delivers professional results without the bulk and expense of larger equipment.
Specifications of Small Trailer Concrete Pump
| Spec/Model | YG-10 | YG-20 | YG-30 | YG-40 |
| Work efficiency | 6m³/h | 12m³/h | 15-18m³/h | 20-22m³/h |
| Motor power | 15kw | 22KW | 37KW | 45KW |
| Working pressure | 15MPa/10MPa | 18MPa/12MPa | 18MPa/15MPa | 23MPa/15MPa |
| Aggregate size | 0.5-1.5cm | 0.5-2cm | 0.5-2cm | 0.5-2cm |
| Vertical/Horizontal conveying distance | 20m/50m | 40m/80m | 80m/100m | 120m/260m |
| Diameter of conveying pipe | 80mm | 80mm | φ80(100)mm | φ100(80)mm |
| Weight | 600KG | 1600kg | 2200kg | 2400kg |
| Dimensions | 1800*700*1100mm | 3400x1200x1600mm | 3800x1500x1600mm | 4000x1500x1550mm |
| Standard configuration | 10m steel pipe, 10m hose | 40m steel pipe, 10m hose | 90m φ80 steel pipe, 10m hose | 120m φ80 steel pipe, 10m hose |
Key Advantages of a Small Trailer Concrete Pump
- Easy to Transport:The machine attaches to any standard trailer hitch. It weighs as little as 600 kg. A pickup truck pulls it without special permits. This saves transport costs. It also eliminates the need for flatbed trucks or cranes. The pump arrives on site quickly and sets up in minutes.
- Fits Tight Spaces:Standard pumps are too wide for many job sites. This machine is compact. The YG-10 measures only 1800×700×1100mm. It passes through garden gates. It fits in elevators. It works in basements and backyards. Contractors can place concrete where larger equipment cannot reach. This is a true portable concrete pumping machine for restricted areas.
- Lower Operating Costs:Electric motors cost less to run than diesel engines. There is no fuel to buy. There are fewer moving parts to maintain. The hydraulic system is efficient and reliable. Daily operating expenses are significantly lower than full-size pumps. This makes the small concrete pump an economical choice for small and medium projects.
- Simple to Operate:The control panel is straightforward. One operator manages the entire pumping process. There is no complex training required. The machine starts, pumps, and cleans up with minimal effort. This reduces labor costs and speeds up the work. A mobile concrete pump like this keeps crews small and productive.
- Reliable Performance:The hydraulic system maintains steady pressure throughout the pour. Concrete flows smoothly without surging or blocking. The pump handles aggregates up to 2 cm. It works with standard concrete mixes. The machine runs for hours without overheating or losing power.
Real User Cases of Small Trailer Concrete Pump
Case 1 – Texas, United States
A residential contractor in Austin, Texas, was struggling with concrete pours on suburban house slabs. Full-size pump trucks cost over $1,000 per day. They also could not fit through the narrow gates of many properties. He purchased a YG-20 Small Concrete Pump.
“This machine changed how we work. It tows behind my pickup. It fits through standard gate openings. We now pour slabs in half the time. Labor costs dropped because we need fewer workers on site. The pump paid for itself in less than six months.” – Mark, Austin, TX
Case 2 – Ontario, Canada
A renovation contractor in Toronto used the YG-30 for basement floor pours and foundation repairs. Access was through narrow stairways and standard doorways. The 15-18 m³/h output kept the job moving efficiently.“The YG-30 is compact enough to fit through basement entrances. It pours concrete faster than our old method. My crew loves how easy it is to clean at the end of the day. This mini concrete pump machine has been a solid investment for our business.” – Sarah, Toronto, Canada
FAQ
Q:What is a Small Trailer Concrete Pump?
It is a compact, towable concrete pump. It moves concrete from the mixer to the pour point through a pipeline. The machine is lightweight and fits through standard doorways and gates.
Q:How far can it pump concrete?
Vertical distance ranges from 20 meters on the YG-10 to 120 meters on the YG-40. Horizontal distance ranges from 50 meters to 260 meters. This covers most residential and small commercial projects. It works effectively as both a horizontal concrete pump and a vertical mini concrete pump.
Q:What size aggregate can it handle?
The YG-10 handles aggregates up to 1.5 cm. The other models handle aggregates up to 2 cm. This works with standard ready-mix concrete.
Q:How do I get a price quote for the Concrete Pump?
Contact YG Machinery directly for a price quote. Provide your project details and model preference. The team will send accurate pricing and delivery information.
Why choose YG Machinery
YG Machinery offers customization options for the Small Trailer Concrete Pump. Customers can choose different pipe sizes, voltage configurations, and paint colors. Custom hose lengths and trailer hitch types are also available. Other products include the Integrated Rock Drill and Splitter, Portable Screw Air Compressor, and Foldable Prefab House. Contact YG Machinery for a price quote and customization details.【WhatsApp/WeChat/Phone/Skype】+86 13937183602
