A paper cup forming machine turns flat paper rolls into finished cups in one continuous process. These machines handle feeding, sealing, bottom forming, and counting automatically. Businesses use this equipment to produce cups for coffee shops, restaurants, and events. The right paper cup making machine helps you meet customer demand while keeping labor costs low. Whether you need a small unit for a startup or a high-speed model for large production, the right paper cup manufacturing equipment makes a difference.
Specifications of YG Paper Cup Forming Machine
| Model | YG-DP10 | YG-DP16 | YG-GS120 |
| Production Speed (pcs/min) | 80-110 | 70-90 | 100-120 |
| Voltage | 380V/50Hz, Three Phase | 380V/50Hz, Three Phase | 380V/50Hz, Three Phase |
| Paper Cup Specifications (oz) | 3oz-12oz | 3oz-16oz | 3oz-16oz |
| Machine Package Size (L*W*H, mm) | 2150x1100x1750 | 2150x1100x1950 | 2180x1050x1600 |
| Paper Stock / Material Requirements | 160-350g Single & Double PE Coated Paper | 160-350g Single PE Coated Paper | Single & Double Coated Paper |
| Power (KW) | 7.8KW | 5.5KW | 7KW |
| Weight (Kg) | 1700Kg | 1600Kg | 2100Kg |
| Paper Thickness Requirements (g/㎡) | 150-350g/㎡; ±20g/㎡ | ||
| Gas Supply Requirements | 0.6-0.8Mpa; 0.4m³/min | ||
| Cup Body Sticking Method | Ultrasonic Heating | ||
| Bottom Heating Method | Nest Bottom Heating (5 groups) | ||
| Molds Customization | Customizable According to Customer Requirements |
Key Advantages of This Paper Cup Making Machine
- High Production Speed:The YG-GS120 model produces 100-120 cups per minute. This speed allows you to fill large orders quickly. Faster output means more cups for sale in less time. For businesses with high demand, this speed keeps production running smoothly.
- Flexible Cup Size Options:These machines support cup sizes from 3oz to 16oz. You can switch between sizes by changing molds. This flexibility lets you serve different customers. Produce small cups for espresso or large cups for iced drinks. One paper cup manufacturing machine handles multiple sizes.
- Reliable Ultrasonic Sealing:The cup body sticking method uses ultrasonic heating. This creates strong, clean seals. Ultrasonic sealing reduces leaks and improves cup quality. Customers receive cups that hold beverages without issues. This technology also reduces waste compared to traditional heating methods.
- Durable Construction:These machines weigh between 1600kg and 2100kg. Heavy-duty build means stable operation over years of use. The open cam driving system and automatic lubrication keep parts running smoothly. Less wear means lower maintenance costs.
- Easy Operation:PLC touch screen controls make operation simple. Workers learn quickly without extensive training. Photoelectric sensors detect problems and stop the machine automatically. This protects the equipment and reduces scrap.
- Energy Efficient:Power consumption ranges from 5.5KW to 7.8KW. These machines use energy-saving technology. Lower power use means reduced operating costs over time.
Applications for Paper Cup Forming Equipment
- Coffee Shops and Cafés:Coffee shops need reliable cups for hot beverages. A paper cup forming equipment line produces cups that hold heat well. Single PE coated paper works for hot drinks. Cups stay strong and safe for customers.
- Fast Food and Takeaway:Restaurants need cups for cold drinks and soups. Double PE coated paper prevents condensation. Cups remain sturdy even with ice and cold liquids. Fast service requires consistent cup quality.
- Ice Cream and Frozen Desserts:Ice cream shops use cups for scoops and sundaes. These cups need to handle cold temperatures. The right paper cup making machinery produces cups that stay firm in freezers.
- Events and Catering:Weddings, parties, and exhibitions use disposable cups. Custom printing options let you add logos or designs. Branded cups promote businesses while serving drinks.
- Offices and Institutions:Offices, schools, and hospitals need cups for daily use. Automated production keeps costs low for bulk orders. Reliable paper cup manufacturing equipment ensures steady supply.
FAQ
What materials can this paper cup forming machine handle?
The machine works with single and double PE coated paper from 160-350g/㎡. Single PE works for hot drinks. Double PE works for cold drinks. The YG-GS120 model handles both types.
Can I change cup sizes on the same machine?
Yes. Molds are customizable according to customer requirements. You can switch between 3oz and 16oz sizes. This flexibility lets you produce different cups without buying multiple machines.
How fast does the machine produce cups?
Production speed ranges from 70 to 120 cups per minute depending on the model. The YG-GS120 reaches 100-120 cups per minute. Speed varies based on cup size and paper quality.
What power supply does the machine need?
All models run on 380V/50Hz, three phase power. Check your facility’s power supply before purchase. We can advise on compatibility.
Does the Paper Cup Forming Machine require compressed air?
Yes. Gas supply requirements are 0.6-0.8Mpa at 0.4m³/min. This powers certain functions in the forming process.
What is the warranty and support?
YG Machinery provides warranty coverage and technical support. Spare parts are available. Our team offers installation guidance and training.
YG Machinery: Your Trusted paper cup machine Partner
YG Machinery manufactures a wide range of industrial equipment. Beyond paper cup forming machines, the company produces Hot Melt Road Marking Machine for road construction, Glass Installation Robot for building projects, and Static Concrete Pump for construction sites. With years of experience in manufacturing and export, YG Machinery serves customers worldwide. Each machine undergoes testing before shipping. We provide factory-direct pricing, quick quotes, and responsive service. Contact us today for a price on your paper cup production line. Let us help you find the right paper cup machine for sale that fits your budget and production goals.【WhatsApp/WeChat/Phone/Skype】+86 13937183602
