A toilet paper roll making machine turns large jumbo paper rolls into finished toilet paper products ready for packaging and sale. This equipment integrates rewinding, embossing, perforating, cutting, and sealing functions into one streamlined production line. Whether you are starting a new tissue production business or expanding an existing operation, the right tissue paper manufacturing machine helps you achieve consistent output with less manual labor. Below is a detailed look at the specifications, advantages, applications, and support options for this essential paper processing equipment.
Specifications of Toilet Paper Roll Making Machine
| Parameter | Specification |
| Model | YG1575 |
| Applicable Raw Paper | 2-3 plies 14~23gsm, Wood pulp paper |
| Raw Paper Width | Max 2100mm |
| Raw Paper Dia | Max 2200mm |
| Finished Size | Φ60~130 mm |
| Finished Core Dia | Φ35mm-Φ50mm |
| Raw Paper Core Dia | 3″(76.2 mm) |
| Perforation | Spiral perforating knife, Chain wheel positioning |
| Production Speed | 200 m/min |
| Parameter Design | LCD Touch Screen |
| Control | PLC |
| Paper Feeding | 3 Unwinding stands, controlled by pneumatic |
| Air Pressure | 0.5 MPs |
| Power | 380V, 50hz |
| Packaging | Wooden box |
These specifications apply to the standard model. Contact us for a detailed quote based on your specific production needs.
Advantages of Toilet Paper Roll Making Machine
- High-Speed Production:This toilet paper machine operates at a speed of 200 meters per minute. It produces finished rolls quickly and consistently. This high output helps you meet large orders and tight delivery schedules.
- Fully Automated Operation:The automatic toilet paper making machine handles unwinding, embossing, perforating, rewinding, gluing, and cutting without constant manual intervention. The PLC control system with an LCD touch screen allows operators to adjust settings easily. Automation reduces labor costs and minimizes human errors.
- Customizable Finished Products:You can adjust finished roll diameter from Φ60mm to Φ130mm and core diameter from Φ35mm to Φ50mm. This flexibility lets you produce different products for different markets. Options include core paper rolls, coreless rolls, and various perforation lengths.
- Durable Construction:Heavy-duty steel frames and corrosion-resistant components ensure long service life. With proper maintenance, this paper roll making machine can operate reliably for 10 to 15 years or more. This durability protects your investment over the long term.
- Precision Perforation System:The spiral perforating knife with chain wheel positioning delivers clean and accurate perforations. This system ensures consistent tear lines on every roll, improving user experience and product quality.
- User-Friendly Design:The LCD touch screen and PLC control make operation simple. Modular construction allows quick part replacement and easy maintenance. This design minimizes downtime and keeps your production line running smoothly.
FAQ
Q:What raw materials does this machine process?
The machine processes 2 to 3 plies of wood pulp paper with a weight range of 14 to 23 gsm. It handles jumbo rolls up to 2100mm in width and 2200mm in diameter.
Q:What is the production speed?
The standard production speed is 200 meters per minute. Actual output depends on roll size and paper material.
Q:What finished roll sizes can this machine produce?
Finished roll diameter ranges from Φ60mm to Φ130mm. Core diameter ranges from Φ35mm to Φ50mm. These parameters are adjustable.
Q:What control system does the machine use?
The machine uses a PLC control system with an LCD touch screen interface. Operators can set parameters, monitor production, and adjust settings easily.
Q:What is the price of a toilet paper roll making machine?
Prices vary by configuration, capacity, and features. Contact our sales team for a quote based on your specific needs. We offer competitive pricing and flexible payment terms.
Q:Do you offer installation and after-sales support?
Yes. Engineers are available to assist with installation and commissioning. We provide warranty coverage, spare parts support, and technical training.
YG Machinery: Your Trusted Partner for Paper Production Equipment
YG Machinery is a leading Chinese manufacturer of paper processing equipment. We specialize in toilet paper roll making machines, tissue paper making machines, and complete production line solutions. Our equipment serves manufacturers worldwide with reliable performance and competitive pricing.
Beyond paper machinery, YG Machinery also offers the 20FT Expandable Container House for mobile workspaces, the Fog Cannon Machine for dust suppression, and the Electric Sweeper for industrial cleaning. These products reflect our commitment to diverse, high-quality industrial solutions.
Every machine undergoes rigorous quality testing before shipment. We provide installation guidance, operator training, and responsive after-sales support. Contact us today for a toilet roll manufacturing machine price tailored to your production goals. Our team is ready to answer your questions and help you select the right equipment for your business. Get your quote now.【WhatsApp/WeChat/Phone/Skype】+86 13937183602
