A mini mobile concrete batching plant is a self-contained system that mixes cement, aggregates, water, and additives right at the job site. Unlike large stationary plants, this equipment sits on a wheeled chassis and moves easily between locations. It eliminates the need to order ready-mix concrete from distant suppliers. Users can produce fresh concrete on demand, saving both time and transport costs. This makes the concrete batching plant a practical choice for contractors who need flexibility and efficiency. Whether the project is small or medium-sized, this plant delivers consistent concrete exactly when and where it is needed. For those looking to buy, this unit offers a cost-effective way to control concrete quality on site.
Specifications of YG Mini Mobile Concrete Batching Plant
| Model | YG20 | YG30 | YG60 | YG100 |
| Production capacity (m³/h) | 20 | 30 | 60 | 100 |
| Concrete mixer | YG500 | YG750 | YG1500 | YG2000 |
| Aggregate feeding mode | Belt conveyor | Belt conveyor | Belt conveyor | Belt conveyor |
| Aggregate size (mm) | 80/60 | 80/60 | 80/60 | 80/60 |
| Discharging height (m) | 1.5 | 1.5 | 1.5 | 1.5 |
| Aggregate weighing accuracy (%) | ±2 | ±2 | ±2 | ±2 |
| Cement weighing accuracy (%) | ±1 | ±1 | ±1 | ±1 |
| Water weighing accuracy (%) | ±1 | ±1 | ±1 | ±1 |
| Additive weighing accuracy (%) | ±1 | ±1 | ±1 | ±1 |
| Control system | Panel | Computer | Computer | Computer |
| Total power (kW) | 42 | 46 | 67 | 77.5 |
| Total weight (t) | 12 | 13 | 14.5 | 26 |
The YG20 and YG30 are ideal for small projects. The YG60 and YG100 handle larger workloads. All models use a belt conveyor for aggregate feeding. The weighing systems are precise, with aggregate accuracy at ±2% and cement, water, and additive accuracy at ±1%. This ensures every batch meets quality standards. The control system ranges from a simple panel to full computer control, depending on the model.
Advantages of the Mini Mobile Concrete Batching Plant
- Easy to Move – This batching plant portable design allows towing between sites without disassembly. It sets up quickly and moves as the project progresses. This is a key benefit for contractors who work on multiple job sites.
- Saves Money – Producing concrete on site cuts transport costs. There is no need to pay for delivery from faraway plants. It also reduces material waste and lowers labor needs compared to manual mixing. The small concrete batch plant offers a lower initial investment than large fixed stations.
- Quick Setup – Most installation and testing are done at the factory. On site, only a small amount of connection work is needed. The plant can start producing concrete within a short time. This saves valuable project time.
- Small Footprint – The compact design fits tight spaces. Urban construction sites and road repair zones often have limited room. This small portable concrete batch plant works well in those conditions.
- Simple to Operate – The control interface is user-friendly. Even first-time operators can learn quickly. The automation reduces the need for highly skilled workers.
- Reliable Output – The integrated weighing system ensures each batch is accurate. This produces consistent concrete strength. For a concrete batching plant, accuracy is essential for structural safety.
Applications of the Mini Mobile Concrete Batching Plant
- Small to Medium Construction – This compact concrete plant produces concrete for foundations, floor slabs, and structural work. It is especially useful where space is limited or site access is difficult.
- Remote Area Projects – In rural or off-grid locations, a batching plant portable enough to travel ensures timely concrete supply. There is no need to rely on distant ready-mix plants. This is critical for infrastructure, housing, and mining operations.
- Road Repairs and Maintenance – The mini concrete mixer plant can be deployed quickly to patch highways, bridge decks, or walkways. This minimizes traffic disruption and delivers durable results.
- Precast Element Production – Users can cast pavers, kerbstones, and concrete blocks right on site. This reduces logistics costs and speeds up production.
- Foundation and Piling Work – The plant delivers precise amounts of concrete directly where needed. This ensures structural stability and keeps the project moving.
- Farm and Agricultural Projects – Building silos, barns, fences, and driveways becomes easier with on-site concrete production.
FAQ
Q: What is the capacity of a mini mobile batching plant?
A: YG models range from 20 m³/h to 100 m³/h. The YG20 and YG30 suit small projects, while the YG60 and YG100 handle larger needs.
Q: How long does it take to set up?
A: Setup takes only a short time. Most assembly is done at the factory. On-site connection work is minimal.
Q: Can this plant move between sites easily?
A: Yes. The wheeled chassis allows towing from one location to another. No complicated disassembly is required.
Q: What is the price of a small portable concrete batch plant?
A: The price depends on the model, configuration, and capacity. YG offers factory-direct pricing with no middlemen. Contact YG for a quote based on project needs.
Q: Is training required to operate the plant?
A: The control system is simple and intuitive. Most operators can learn quickly. Basic training is available if needed.
Q: What after-sales support does YG provide?
A: YG offers a warranty period and online technical support. Free replacement parts are provided for covered issues. The team follows a process from consultation to after-sales follow-up.
YG Machinery – Manufacturer of Mini Mobile Concrete Batching Plant
YG Machinery is a professional manufacturer of construction equipment based in Zhengzhou, China. As a portable concrete plant, this equipment is designed for easy relocation and fast setup. The company has over 20 years of engineering experience. YG produces a wide range of machinery, including the Solar Pile Driver for renewable energy projects and the Durable Rock Splitter Machine for rock and concrete demolition. All products are built for durability and performance. YG provides factory-direct pricing, comprehensive warranties, and responsive after-sales service. For a quote on the Mini Concrete Mixer Plant or other equipment, contact us today.【WhatsApp/WeChat/Phone/Skype】+86 13937183602
