A Mini Concrete Pump Machine is a compact piece of equipment designed to move concrete through pipes using hydraulic pressure. It saves time and labor on job sites. This machine replaces slow manual methods like wheelbarrows and buckets. It pumps concrete steadily to floors, walls, and columns. Contractors use it for residential buildings, road work, and small commercial projects. The machine is easy to transport and fits into tight spaces where large trucks cannot go. Whether you need a small concrete pump for a house foundation or a concrete pump small portable unit for multiple sites, this equipment gets the job done. It is also known as a mini cement pump or small portable concrete pump in many markets.
Specifications of Mini Concrete Pump Machine
| Model | YG-20 | YG-30 | YG-40 | YG-50 |
| Motor Power | 22KW | 37KW | 45KW | 55KW |
| Max. Outlet Pressure | — | 26MPa | 28MPa | 28MPa |
| Max. Theoretical Throughput | — | 16-18m³/h | 20-22m³/h | 35m³/h |
| Max. Aggregate Particle Size | — | ≤20mm | ≤30mm | ≤40mm |
| Vertical Conveying Distance | 40m | 80m | 120m | 150m |
| Horizontal Conveying Distance | 80m | 140m | 260m | 300m |
| Conveying Pipe Diameter | 80mm | φ80(100)mm | φ100(80)mm | Φ125/100mm |
| Machine Weight | 1600kg | 2200kg | 2400kg | 2500kg |
| Dimensions (mm) | 3400x1200x1600 | 3600x1500x1600 | 4000x1500x1550 | 4200x1700x1750 |
The YG-20 is the lightest model at 1600kg. It fits small projects with a 40m vertical reach. The YG-50 is the most powerful unit. It delivers 35m³/h throughput and reaches 150m vertically. Working pressure reaches up to 28MPa on larger models for consistent output. All models use electric motors for quiet, clean operation. You can check the price for each model and compare features based on your project needs.
Advantages of Mini Concrete Pump Machine
- Compact Size for Tight Job Sites:The mini cement pump has a small footprint. It moves easily through narrow streets and crowded urban areas. Large pump trucks cannot enter many residential construction sites. This machine fits where others cannot. It works well for projects with limited space and restricted access. The compact design also makes storage simple when not in use.
- Easy Transport Between Sites:This small concrete pump is portable. It can be towed or loaded onto a truck for quick relocation. Contractors who work on multiple projects benefit from this mobility. You do not need special permits or oversized loads. The machine moves from one job to the next with minimal effort. This saves time and reduces transportation costs.
- Stable and Continuous Pumping:The hydraulic system delivers steady concrete flow. There are no sudden stops or interruptions. The pump maintains consistent pressure even during long pours. This reliability reduces waste and ensures quality concrete placement. Workers can focus on finishing rather than troubleshooting equipment. The stable output also reduces the risk of pipe blockages.
- Lower Labor Costs:Using a concrete pump small portable unit reduces the number of workers needed. One operator can manage the machine. Fewer workers mean lower payroll expenses. The machine also speeds up pouring time. Projects finish faster, which saves money on labor and equipment rental. Many contractors report labor cost reductions of 25% to 40% after switching to a mini concrete pump.
- Simple Operation and Maintenance:The controls are straightforward. Operators can learn to run the machine after short training. Daily maintenance is quick and easy. Grease points are easy to reach. Wear parts like pistons and cutting rings are simple to replace. This keeps downtime to a minimum. The machine stays productive with basic care and regular inspections.
Customer Case of Mini Concrete Pump Machine
Case 1: Residential Construction in Brazil
A Brazilian contractor worked on small residential buildings in suburban areas. The site had narrow roads. Large pump trucks could not enter. The crew used wheelbarrows to move concrete. This method was slow and required many workers. Labor costs were high, and the project fell behind schedule.
The contractor bought a small portable concrete pump from YG Machinery. The pump was easy to move into the site. It pumped concrete steadily to upper floors. The project finished faster. The contractor saved money on labor and completed more jobs. The client said: “The machine fits our work perfectly. It is compact, efficient, and easy to operate”.
Case 2: Urban Development in Colombia
A real estate developer in Medellin, Colombia, built low-rise residential buildings. The construction sites were in crowded city areas. Traditional pump trucks were too large and expensive to rent. The developer needed a cost-effective solution.
The developer purchased a YG-30 small concrete boom pump. The portable concrete pump moved through narrow streets with ease. It delivered concrete quickly to each floor. The project stayed on schedule and within budget. The developer said: “This small pumping equipment is compact and amazingly efficient. It completely exceeds my expectations”.
FAQ
Q:What is a Mini Concrete Pump Machine?
It is a compact machine that pumps liquid concrete through pipes to job site locations. It replaces manual transport methods like wheelbarrows and buckets.
Q:How do I choose the right model?
Match the model to your project size and height requirements. The YG-20 suits small jobs with 40m vertical reach. The YG-50 handles larger projects with 150m vertical reach. Also consider the daily concrete volume you need to pump.
Q:What is the maximum pumping distance?
The YG-50 model pumps concrete up to 150m vertically and 300m horizontally. Smaller models have shorter reach. Check the specifications table for each model’s distance.
Q:Is the machine easy to maintain?
Yes. Daily maintenance takes only a few minutes. The grease points are easy to access. Replacement parts like pistons and cutting rings are simple to change. Routine care keeps the machine running reliably.
Q:Can I use this machine for different types of projects?
Yes. The machine works for residential buildings, road construction, tunnels, and small commercial projects. It handles various aggregate sizes up to 40mm on larger models. It is a versatile tool for many construction applications.
YG Machinery – Supplier of small concrete mixer pump
YG Machinery is a professional manufacturer of construction equipment. The company produces a full range of Mini Concrete Pump Machine, Excavator Hydraulic Shears, Mini Mobile Concrete Batching Plants, and Concrete Wall Sawing Machine,etc.Whether you need a small concrete boom pump for high-rise work or a small concrete mixer pump for on-site mixing, YG Machinery has the right solution for your project. Contact YG Machinery today for a free quote and expert advice on choosing the best Mini Concrete Pump Machine for your needs.【WhatsApp/WeChat/Phone/Skype】+86 13937183602
